Size:
– Outer Diameter: Options range from DN15-DN400
– Thickness: Depending on size, typically from 2mm to 10mm.
– Length: Standard lengths are 4m, customizable upon request.
Material: Acrylonitrile Butadiene Styrene (ABS)
– Density: ~1.04 g/cm³.
– Color: Typically, red, or gray.
Mechanical Properties:
– Tensile Strength: ≥ 40 MPa.
– Flexural Strength: ≥ 65 MPa.
– Hardness: Shore D approximately 75 – 85.
– Working Temperature: -30°C to +60°C.
– Thermal Expansion Coefficient: 1.1 x 10⁻⁴ cm/cm/°C.
Chemical Properties:
– Corrosion Resistance: Excellent resistance to acids, bases, salts, and many other chemicals.
– UV Resistance: Can be enhanced with UV stabilizers for increased outdoor durability.
– Water Resistance: Impermeable, suitable for water supply and drainage systems.
Electrical Properties:
– Electrical Resistivity: Very high, suitable for electrical insulation applications.
